4 Fibers Multimode Multi-core Armored Optical Indoor Cable

SKU#:FITB27464SIF
Model#: MCA-MM-FITB4
Price: US$ 0.77 ( Per Meter )
Sold: 4070
Availability: In Stock
Length:

Roll(s):
Direct Factory Price Contact Us: Sales@fiberinthebox.com
QtyPrice QtyPrice QtyPrice QtyPrice QtyPrice
1-9US$ 0.77 10-19US$ 0.75 20-29US$ 0.74 30-49 Sign in to view 50+ Sign in to view
fiberinthebox-bbb-a-plus-certification fiberinthebox-product-certification
4 Fibers Multi-mode Multi-core Armored Optical Indoor Cable

Multi-core Armored Optical Indoor Cable 900μm flame-retardant tight buffer fibers ,aramid yarn ,PVC or LSZH (Low smoke, Zero halogen, Flame-retardant ) jacket.

Characteristics
Tight buffer fiber ease of stripping The jacket anti-corrosion, anti-water, anti-ultraviolet radiation, flame retardant and harmless to environment etc; Soft, flexible, easy to splice, and with big capacity data transmission; All dielectric structure protect it from electromagnetic influence Crush resistance flame retardant characteristics
Applications
Multi core optical fiber jumper and pigtail Indoor any purpose cable distribution Backbone distribution cable in building

Optical Characteristics

Fiber So

Multimode

G.651

A1a:50/125

Graded-index fiber

A1b:62.5/125

Singlemode

G.652(A、B、C)

B1.1:Conventional fiber

G.652D

B2: Zero dispersion shifted

G.655

B1.2 :Cut-off wavelength shifted

G.657(A1、A2 、B3)

B4: Main technical data for positive

dispersion shifted single-mode fiber

Technician Characteristics

Fiber count

Cable Diameter (mm)

Cable Weight (kg/km)

Tensile (N)

Crush (N/100mm)

Min. Bend Radius (mm)

Long/ Sho term

Long/ Sho term

Dynamic/ Static

4

5

19

130/440

200/1000

20D/10D

6

5.2

23

130/440

200/1000

8

5.5

26

130/440

200/1000

12

6.5

36.5

200/660

200/1000

16

7.5

44.5

200/660

200/1000

24

8.2

54.5

200/660

200/1000
