16E1+4*10/100M PDH Fiber Optical Multiplexers Singlemode Dual Fiber 20KM 19 Inch Rack(with the orderwire phone)

SKU#:FITB82690MJD
Model#: PDH-16E1-4-100M-19-P
Price: US$ 320.63
Sold: 542
Availability: In Stock
Qty:
Direct Factory Price Contact Us: Sales@fiberinthebox.com
QtyPrice QtyPrice QtyPrice QtyPrice QtyPrice
1-9US$ 320.63 10-19US$ 314.21 20-49US$ 307.80 50-99 Sign in to view 100+ Sign in to view
fiberinthebox-bbb-a-plus-certification fiberinthebox-product-certification
16E1+4*10/100M PDH Fiber Optical Multiplexers Singlemode Dual Fiber 20KM 19 Inch Rack(with the orderwire phone)

The 16E1+4*10/100M PDH Fiber Optical Multiplexers is a fiber media transpo for 16E1 + 4* 10/100BaseT transmission. The BNC model provides unbalanced 75 Ohm coaxial connections while the RJ-45 model provides balanced 120 Ohm connections over twisted pair wiring. All media conve ers are available with either multi-mode or single-mode optical tranceivers and with connectors for SC, ST, or FC. In single mode they are available in up to 120 km versions reach, which will provide the ability to transmit and receive data using only a single optical fiber pair.

Specifications :
Single mode dual optical po -16 channels of E1 po sLow power consumption ISO ce ificationOptional Power redundancy to ensure stable system Optional fiber redandancy are provided Optional function of ALS and SNMPWith the orderwire phone
Main Feature :
The 16E1 to fiber multiplexer 4 Enthernet po share 10M or 100M bandwidth Provide function of 16E1 remote loop,fiber local loop,and 1 interface phone Optional power 1+1 to ensure stable system Two fiber two direction and single fiber two direction 1+1 power, 1+1 fiber, orderwire phone and the ALS and SNMP are optinal,Please state the requirement when in order 16E1 PDH multiplexer realizes 1~16E1 transmission over fiber E1 spur track loop back testing features, easy to be installed and maintenance External dimensions: 19-inch rack (with distribution frames rack) Provided the 1+1 fiber back up Optical optional by customer 's requirement
Interface:
E1 interface
16E1 interface for 16E1
E1 rate: 2.048Mb/s±50ppm
Code type: HDB3

E1 Style: Pinfet

E1 comply with ITU-T G.703
Jitter compl y with ITU-T G.823 and G.742
E 1 with DB37. Be ab le to be with 75Ω (BNC) or 120Ω (RJ45) by adaptor in the accessory
Fiber
Optical rate: 42.240Mbit/s

optical style:4B5B

Default: dual fiber, single mode, 20km (40km optional)
connector: FC /SC/ST
wavelength:1310nm
Receiver sensitivity:≤ -38dBm(BER ≤ 10-11)
Ethernet
1 Ethernet po s with RJ45 connector

MAC address table capability : 1024

MAC address table aging time
The minimum frame length : 64bytes
The maximum frame length : 1916 bytes
Working mode : full/half duplex configurable
Suppo VLAN, Stream control
Bandwidth : 4 Ethernet po s shared 10 or 100M bandwidth
Power Requirements :
Power Input: AC /DC optionalAC180V~240V DC-36V~DC-72V DC+20V~DC+36VPower Consumption: <6Walt
Working Environment:
Operating Temperature: 0℃ ~+50℃Storage Temperature: -40℃ ~+70 ℃
