E1 to Ethernet 10/100BaseT Mini Interface/Protocol converter

SKU#:FITB31380SAI
Model#: FSC-604
Price: US$ 124.45
Sold: 3190
Availability: In Stock
Qty:
Direct Factory Price Contact Us: Sales@fiberinthebox.com
QtyPrice QtyPrice QtyPrice QtyPrice QtyPrice
1-9US$ 124.45 10-19US$ 121.96 20-49US$ 119.47 50-99 Sign in to view 100+ Sign in to view
fiberinthebox-bbb-a-plus-certification fiberinthebox-product-certification



4E1 to Ethernet 10/100Base-T Protocol/Interface Conve er is designed to provides easy conversion from 1 to 4 E1 channels to Ethernet interface.

Features:
  • According with IEEE 802.3, suppo 10Base-T, 100Base-T
  • Suppo flexible setting of 1 to 4 E1 channels, auto detect the number of E1 channels and time-delay, select available E1 channels and more;
  • Provide 2 loop functions: local E1 loop, remote E1 loop.
  • Ethernet transmission transparent,suppo AUTO-MDIX, straight and crossover auto-adapt.
  • Can transmit super-long frame of IEEE 802.1Q, suppo Ethernet exchanger with VLAN function.
  • Suppo E1 channel hot plug, and auto detect available E1 channels.
  • Suppo reset remote system from local system.
  • 4 E1 can have 10 ms time-delay, CRC alarm limitation can auto insulate bad-quality transmit channel by configuration, and is single direction insulation. when one direction error rate over limitation, cut only this direction, the other direction not affected.
  • Power supply option: AC220V, DC-48V. The positive and negative terminal can be exchanged for DC-48V, easy for installation and maintenance.

Specifications:
  • E1 interface parameter:
  • Channel capacity: 4 Channels
  • Bit Rate: 2.048 Mb/s ±50 ppm
  • Line Code: HDB3
  • Line Impedance: 120 Ohm / 75 Ohm
  • Connector: RJ-45 or BNC
  • Pulse Shape: ITU-T G.703.
  • Jitter Performance: ITU-T G.823
  • Clocking: internal-clock, line-clock

Ethernet interface:
  • Interface Rate: 10/100Mbps
  • Duplex: half and full duplex self-adapt.
  • Interface character: match IEEE802.3, IEEE802.1Q (VLAN)
  • Connector: RJ45, suppo auto-mdix
  • MAC address capability: 4096

Power
  • DC: -48V (-36 to -72V); +24 V (Optional)
  • AC:  90 to 260 VAC ; 47 ~ 63Hz
  • Power Interface: DC power terminal/AC socket
  • Power Consumption: 8 W maximum

Working environment
  • Operating temperature: 0 to 50°C
  • Storage temperature: -20  to +70°C
  • Relative humidity: 5% to 90% (25°C no condense)
