6M(19.7ft) 40GBASE QSFP+ to 8xLC Connetor Breakout Active Optical Cable

SKU#:FITB35327DRE
Model#: QSFP-8LC-AOC-6-xx
Price: US$ 224.42
Sold: 1699
Availability: In Stock
:
:
:
:
:
Qty:
Direct Factory Price Contact Us: Sales@fiberinthebox.com
QtyPrice QtyPrice QtyPrice QtyPrice QtyPrice
1-4US$ 224.42 5-9US$ 219.93 10-19US$ 215.44 20-49 Sign in to view 50+ Sign in to view
fiberinthebox-bbb-a-plus-certification fiberinthebox-product-certification
QSFP-8LC-AOC-6-xx
40GBASE QSFP+ to eight LC Connetor Breakout Active Optical Cable are a high performance, low power consumption, long reach interconnect solution suppo ing 40G Ethernet, fiber channel and PCIe. It is compliant with the QSFP MSA and IEEE P802.3ba 40GBASE-SR4. QSFP+ Breakout Cable is an assembly of 4 full-duplex lanes, where each lane is capable of transmitting data at rates up to 10Gb/s, providing an aggregated rate of 40Gb/s. QSFP+ Breakout Cable are suitable for sho distances and offer a highly cost-effective way to connect within racks and across adjacent racks. This product is a high data rate parallel active optical cable (AOC), to overcome the bandwidth limitation of traditional copper cable.
All our 40GBASE QSFP+ to LC Connetor(8) Breakout Active Optical Cable are 100% compatible with major brands like Cisco, HP, Juniper, Enterasys, Extreme, H3C and so on. If you would like to order high quality compatible 40GBASE QSFP+ to LC Connetor(8) Breakout Active Optical Cable and get worldwide delivery, we believe Fiberinthebox is your best choice.
Specifications
Connector 1: QSFP+Connector 2: 8 x LC ConnectorLength: 6 meterCable Type: AOC CableFull duplex 4 channel 850nm parallel active optical cableTransmission data rate up to 10.3Gbit/s per channelSFF-8436 QSFP+ compliant housing and hot pluggable electrical interface.Management Interface and digital diagnostic monitoring(DDM) through I2CSuppo Rx output pre-emphasis4ch 850nm VCSEL array4ch PIN photo detector arrayHelix type multi-mode optical fibre cable of up to 100mOFNP (Optical Fibre Non-Conductive Plenum) rated cableDifferential AC-coupled high speed data interfaceHousing isolated from connector groundOperating Temperature: 0 to 70℃RoHS 6 compliant3.3V power supply voltage
Applications
Infiniband transmission at 4ch SDR(2.5Gbit/s), DDR(5Gbit/s) and QDR(10Gbit/s)Multi-channel 10Gb Ethernet transmission up to 4 channelsFiber Channel transmission at 8.5Gbit/s per channel, up to 4 channelsQSFP+ to LC cables with MT connectors for plugging into existing cable runs or patch pannelsCreating a breakout cable with four Duplex LC connectors for po expander applicationsSDR / DDR / QDRData Centers
Ordering Information
Pa No. Data Rate  Length Cable Type Connector Type Temp. Range
QSFP-8LC-AOC-1-xx Up to 40G 1m AOC Cable QSFP+ to 8 x LC 0-70℃
QSFP-8LC-AOC-2-xx Up to 40G 2m AOC Cable QSFP+ to 8 x LC 0-70℃
QSFP-8LC-AOC-3-xx Up to 40G 3m AOC Cable QSFP+ to 8 x LC 0-70℃
QSFP-8LC-AOC-4-xx Up to 40G 4m AOC Cable QSFP+ to 8 x LC 0-70℃
QSFP-8LC-AOC-5-xx Up to 40G 5m AOC Cable QSFP+ to 8 x LC 0-70℃
QSFP-8LC-AOC-6-xx Up to 40G 6m AOC Cable QSFP+ to 8 x LC 0-70℃
QSFP-8LC-AOC-7-xx Up to 40G 7m AOC Cable QSFP+ to 8 x LC 0-70℃
QSFP-8LC-AOC-8-xx Up to 40G 8m AOC Cable QSFP+ to 8 x LC 0-70℃
QSFP-8LC-AOC-9-xx Up to 40G 9m AOC Cable QSFP+ to 8 x LC 0-70℃
QSFP-8LC-AOC-10-xx Up to 40G 10m AOC Cable QSFP+ to 8 x LC 0-70℃
Notes
This new version 40GBASE QSFP+ to LC Connetor(8) Breakout Active Optical Cable opens EEPROM for customer re-coding for different applications.Custom 40GBASE QSFP+ to LC Connetor(8) Breakout Active Optical Cable are available in various lengths and other options.
Packaging
Packed with antistatic bag in a box(Default Customer Options) Specific Labels as Request
Impo ant Notice
OEM and ODM
Combining our extensive design and engineering capability in optical transceiver industry, with our competitive advantages from integrated manufacturing capability, internal supply chain, and cost competitive and scalable operation infrastructure, Fiberinthebox provides OEM, ODM, and contract manufacturing service to world leading customers with our manufacturing facilities in China.We are also mainly engaged in providing complete sets of optoelectronic device solutions to gain more brand extensions and influence for Fiberinthebox in the world. OEM/ODM order is availableWe can supply QSFP-8LC-AOC-1-xx according to your requirements, and design QSFP-8LC-AOC-1-xx label and packaging for your company.We welcome any inquiry for customized QSFP+ Breakout Cables.
Order Procedure
Please contact us with any special requirements you may have, we can help you create a custom solution to meet almost any application. Our engineer will review the project and provide a quotation within 1-2 business days.
a. Email ( sales@fiberinthebox.com )  a rough sketch to a detailed drawing.
b. Our engineer will review the project and provide a quotation within 24 hours.
c. We can arrange production as low as 1 piece and as high as 1,000 pieces in 1~4 business days once an order is placed.
Details

Shipment
International Express: Fedex, DHL, UPS, TNT and EMS.If you have another preferred carrier, please notify us in advance.
FedEx Overnight: It will take 1-3 business days (weekends and holidays excepted) for delivery.
DHL: It will take 2-4 business days (weekends and holidays excepted) for delivery. For Spain, Italy, Brazil and some other countries, items will take longer time to arrive due to customs clearance period.
Save Cost By Buying QSFP+ Breakout Cables From Original Manufacturer Fiberinthebox Directly.
Fiberinthebox is a professional manufacturer & supplier of QSFP+ Breakout Cables. All of our QSFP+ Breakout Cables are tested in-house prior to shipping to guarantee that they will arrive in perfect physical and working condition. We guarantee QSFP+ Breakout Cables to work in your system and all of our QSFP+ Breakout Cables comes with a lifetime advance replacement warranty. If you have questions about QSFP+ Breakout Cables, please feel free to contact us at sales@fiberinthebox.com .
