2x32 Fiber PLC Splitter with Plastic ABS Box Package

SKU#:FITB45574TBU
Model#: PLC-A-2X32
Price: US$ 71.25
Sold: 3592
Availability: In Stock
:
:
:
Qty:
Direct Factory Price Contact Us: Sales@fiberinthebox.com
QtyPrice QtyPrice QtyPrice QtyPrice QtyPrice
1-9US$ 71.25 10-19US$ 69.83 20-49US$ 68.40 50-99 Sign in to view 100+ Sign in to view
fiberinthebox-bbb-a-plus-certification fiberinthebox-product-certification
PLC Splitter is based on planar lightwave circuit technology.
Fiberinthebox 2x32 Fiber PLC Splitter can distribute or combine 2 optical signals into 32 outputs fibers.

The 2x32 PLC Splitter, with1.5m length G.657A Fiber, 0.9mm, 2.0mm, 3.0mm loose tube for choice, and FC, SC, ST & LC connectors for choice, features high reliability, small size, wide operating wavelength range and good channel-to-channel uniformity and provide a cost effective and space saving product suitable to the ever changing networking requirements, and now is widely used in PON networks to realize optical signal power splitting.
ABS Box PLC Splitter Features
Low inse ion loss Low Polarization Dependent Loss Good channel-to-channel uniformity Wide Operating Wavelength: 1260~1650nm High Reliability and Stability Telcordia GR-1209-CORE-2001 Compliant Telcordia GR-1221-CORE-1999 Compliant Fiber input: 0.9 mm, 2.0mm or 3.0mm loose tube fiber for choice Fiber output: 0.9 mm, 2.0mm or 3.0mm loose tube fiber for choice
ABS Box PLC Splitter Applications
Fiber to the point (FTTX) Fiber to the home (FTTH) Passive optical networks(PON, GEPON) Local area networks (LAN) Cable television (CATV) Telecommunication Networks
Mechanical Drawing
1x32, 1x64, 2x32, 2x64: 140*115*18 mm
V.S FBT Coupler, the advantages of PLC are as follows
The loss to different wavelength transmission is not sensitive, so it can meet the transmission requirements of different wavelength High spectral uniformity, can splitter the signals on average Compact structure, small volume The cost advantage is very obvious on many splitter channels
Order Information
Fiberinthebox provides a whole series of 1xN and 2xN splitters that are tailored for specific applications:
a.1x2, 1x4, 1x8, 1x16,1x32, 1x64, 1x128, 2x2, 2x4, 2x8, 2x16, 2x32,2x64, 2x128 Versions of splitters are available.
b. SC/UPC, FC/UPC, LC/UPC, SC/APC, FC/APC, LC/APC connectors or no connectors can be selected as you like
c. 0.9, 2.0, 3.0mm loose tube for input & output fiber type.
d. The length of pigtail can be also customized; usually we will provide you 1.5m, welcome to contact us for more details.

Fiberinthebox provides a various of 1xN and 2xN PLC ABS box splitters. The ABS Box PLC Splitter with its compact structure and small volume, are very convenient for use and can be installed in many places, such as: 19 inch racks, cross connect cabinet and some other devices. For more information about 1x2 Fiber PLC Splitter SMF-28e fiber with Plastic ABS Box Package, please contact us at sales@fiberinthebox.com .
Our Factory

























Specifications
  1×2 1×4 1×8 1×16 1×32 1×64 2×2 2×4 2×8 2×16 2×32
Operating Wavelength (nm) 1260~1650
Insertion Loss (dB) Typical 4.0 7.3 10.5 13.8 16.8 20.5 4.0 7.6 11.2 14.2 17.2
Max(P/S) 4.3/4.5 7.5/7.7 11.0/11.2 14.0/14.2 17.0/17.5 21.0/21.5 4.4/4.7 8.0/8.3 11.7/12.0 14.7/15.0 17.9/18.2
Loss Uniformity (dB) Typical 0.4 0.5 0.6 0.7 0.9 1.3 0.5 1.0 1.0 1.2 1.5
Max 0.6 0.8 1.0 1.4 1.7 2.7 0.8 1.4 1.7 2.0 2.2
Return Loss (dB) (P/S) UPC Min 50/45 5./45 50/45 50/45 50/45 50/45 50/45 50/45 50/45 50/45 50/45
APC Min 55/50 55/50 55/50 55/50 55/50 55/50 55/50 55/50 55/50 55/50 55/50
Polarization Dependent Loss(dB) Typical 0.1 0.1 0.15 0.15 0.15 0.2 0.1 0.1 0.2 0.3 0.3
Max 0.2 0.2 0.3 0.3 0.3 0.4 0.2 0.2 0.4 0.4 0.4
Directivity (dB) Min 55.0 55.0 55.0 55.0 55.0 55.0 55.0 55.0 55.0 55.0 55.0
Wavelength Dependent Loss(dB) Typical 0.2 0.2 0.2 0.3 0.3 0.3 0.3 0.3 0.3 0.5 0.5
Max 0.3 0.3 0.3 0.5 0.5 0.5 0.4 0.4 0.5 0.6 0.8
Temperature Stability(-40~85℃ )(dB) Typical 0.3 0.3 0.3 0.4 0.4 0.4 0.4 0.4 0.4 0.4 0.4
Max 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
Operating Temperature (℃) -40~85
Storage Temperature (℃) -40~85
