Stranded Armored and Sheathed Double Central Loose Tube Cable GYXTW-53
GYXTW-53 Fiber optics cable is armored and sheathed double central loose tube cable, suitable for outdoor use direct buried and aerial duct. This optical fiber cable's max core is 12 cores. Steel-wire parallel member filler protect tube fiber two steel tape armored.Excellent mechanical and environmental performance Compact structure light weight and operated simply.
Features
Steel-wire parallel member.filler protect tube fiber steel tape armored Double-sided PE corrugated steel tape PE outer sheath Two layer sheath for excellent Compact structure, light weight, steel tape armored, excellent crush-resistant performance Parallel double steel wire as strength member
Cable Structure
Structure of the cable package
Our Factory
-
Fiber Coating -
Gel Filling -
SZ Strand -
Sheath cover -
Production Line -
Warehouse
Cable production throughout the cha
Specifications
| OPTICAL CHARACTERISTICS | ||||||
| Glass type | 62.5/125um | 62.5/125um | 50/125um | 50/125um | 50/125um | SM (G652.D) |
| Grade B | Grade A | Grade B | Grade A | OM3 | ||
| P/N Code (X) | 62B | 62A | 50B | 50A | OM3 | 09 |
| Operating Wavelength | 850/1300nm | 850/1300nm | 850/1300nm | 850/1300nm | 850/1300nm | 1310/1550nm |
| Banding Width(MHz. km) | 160/500 | 200/600 | 200/500 | 400/800 | 1500/500 | |
| Attenuation (dB/km) | 3.50/1.50 | 3.00/1.00 | 3.50/1.50 | 3.00/1.00 | 2.70/0.80 | 0.45/0.30 |
| Link Length For 1000M | 200/500 | 275/550 | 500/550 | 550/550 | 1000/600 | |
| Link Length For 10G | 300 | |||||
| Technical Parameters | |||||||||
| Cable Count | Out sheath Diameter | Weight | Minimum allowable Tensile Strength (N) | minimum allowable Crush Load （N/100mm) | Minimum Bending Radius (MM) | Storage temperature | |||
| (MM) | (KG) | short term | long term | short term | long term | short term | long term | （℃） | |
| 2 | 12.0 | 165.00 | 3000 | 1000 | 1500 | 500 | 20D | 10D | -40+60 |
| 4 | 12.0 | 165.00 | 3000 | 1000 | 1500 | 500 | 20D | 10D | -40+60 |
| 6 | 12.0 | 165.00 | 3000 | 1000 | 1500 | 500 | 20D | 10D | -40+60 |
| 8 | 12.0 | 165.00 | 3000 | 1000 | 1500 | 500 | 20D | 10D | -40+60 |
| 10 | 12.0 | 165.00 | 3000 | 1000 | 1500 | 500 | 20D | 10D | -40+60 |
| 12 | 12.0 | 165.00 | 3000 | 1000 | 1500 | 500 | 20D | 10D | -40+60 |
