Features
5 inches high Resolution colorful LCD display
Average splice time: 10 second
Average tube-heat time: 40 second
Lithium battery: up to 180 times of continuous splice and heat
Simultaneous X and Y views with 180 times magnification
New developed technology providing wind and dust resistance
Splicing mode：Auto & Manual
USB Po
Storing 6,000 groups of splice results
Package Include
Machine, Fiber Cleaver, Fiber Stripper, AC Adaptor, Battery, Charger, Spare Electrodes, Cooling Tray, Instruction CD, Quick Reference Guide, Transit Case with Carrying Strap
Fiber Optic Fusion splicer is a must in the process of properly joining two bare optical fibers together. For this kind of fine workmanship product, we Fiberinthebox.com provide one year warranty for each domestic and foreign brand product. If you have any problems or special requirement of the Digital Fiber Fusion Splicer FS2808, please feel free to contact us. We will try our best to provide you the best service.
Specifications
|
Applicable Fibers |
SM, MM, NZ-DS, EDF |
|
Average Splice Loss |
0.02dB(SM), 0.01dB(MM), 0.04dB(NZDS), 0.04dB(EDF) |
|
Return Loss |
≥60dB |
|
Tension Test |
2.0N(200gf) (Standard) |
|
Splicing Program |
50 groups |
|
Protection Sleeve Length |
20mm, 40mm, 60mm |
|
Language |
Chinese, English |
|
Environmental Conditions |
-10°C~+50°C(operation temperature),0~95% RH(humidity), 0~5000m(altitude) |
|
Power Supply |
AC adaptor: 100~240V input voltage, 50/60Hz; 12V, 5A output voltage(DC) DC adaptor: 12V voltage 8AH |
|
Dimensions |
1559W）*165（D）*150（H） |
|
Weight |
2.8kg |
