Portable Visual Fault Locator BD271A(3mw)

BD271 Visual Fault Locator use 650nm laser module as emitter, it is suitable for single mode or multi mode fiber inspection. The output mode can be chosen between CW and 2Hz frequency of light, it is widely used in optical communication, optical components measurement, optical fiberal sensor and other fields.
This BD271A visual fault locator is an essential tool for troubleshooting a optical fiber system, it is really of high quality and good price. As its inspection distance is 1-3km. Please do not hesitate to contact us at sales@fiberinthebox.com if you need it at a large quantity or have any questions or needs of this 3mW optical fiber laser tester.



Optional auto-shutdown
Large LCD display and optional backlight
Battery power display



Maintenance Telecom
Maintenance CATV
Test Lab of Fiber Optic
Optical fiber sensors



1 year warranty is offered for this product. So you can buy it from us with confidence.
Fast delivery, it usually can be shipped out in 1-2 business days, and a large quantity of it can be provided in 3-5 business days.
Our primary delivery method is FedEx overnight, it is very fast, and DHL, EMS, UPS are also available on request. That is to say. We can ship to all the countries that FedEx, DHL, EMS, UPS can arrive. You can also choose to let us give the goods to your own forwarder.



Type	BD271A
Wavelength(nm)	650nm
Emitter Type	FP-LD
Optical Connector	FC/SC/ST
Output Power(mw)	3mw
Modulation Frequencies	CW,2Hz
Power Supply	AAA 1.5V(3pcs batteries)
Fiber Type	SM,MM
Working Time(h)	40
Operating Temperature(°C)	-10~+50
Storage Temperature(°C)	-20~+70
Dimension(mm)	125*65*29mm
Inspection Distance (km)	1-3
