Introduction
The CCTV testerPRO STest-893 is developed for the On-Site installation and maintenance of video monitoring system. It can be used for displaying video, testing video level, controlling PTZ, scanning PTZ address, generating images, capturing data of RS485 and testing LAN cable etc. Its functions, easy operation, and po ability makes it simple for the CCTV technician to install and maintain CCTV system, improving work efficiency and get the labor cost down.
Features
3.5"TFT-LCD, 960 (H) × 240(V) resolution
DC12V power output
Audio input
Adjustable brightness, contrast, color of LCD
Video Level testing, video signals measured in IRE or mV
Automatically identify and adapt the video mode of NTSC and PAL
Colorbar Video signal generator, transmit/receive colorful images
Suppo more than twenty kinds of PTZ controller protocols. For example, PELCO-P, PELCO-D, SAMSUNG etc
PPTZ address scanning, search up the ID of PTZ camera.
Capture the PTZ protocol to assist the setting personnel to find out the control protocol and therefore easily target the problematic equipment.
Suppo RS232 and RS485 interface, the rate 150-19200bps
Powerful in testing LAN cable, measuring the connecting status and displaying the sequence of connection
PTZ(P/L & Zoom) Control: Control the status of P/L, zoom in/out the camera, adjust the ape ure, foci and setting parameters, run and call the preset.
Lithium Ion Polymer Batteries (3.7V DC3000mAh), more reliable, and work 15 hours
Easy for use that the train is almost unnecessary
DC12V power output
Audio input
Adjustable brightness, contrast, color of LCD
Video Level testing, video signals measured in IRE or mV
Automatically identify and adapt the video mode of NTSC and PAL
Colorbar Video signal generator, transmit/receive colorful images
Suppo more than twenty kinds of PTZ controller protocols. For example, PELCO-P, PELCO-D, SAMSUNG etc
PPTZ address scanning, search up the ID of PTZ camera.
Capture the PTZ protocol to assist the setting personnel to find out the control protocol and therefore easily target the problematic equipment.
Suppo RS232 and RS485 interface, the rate 150-19200bps
Powerful in testing LAN cable, measuring the connecting status and displaying the sequence of connection
PTZ(P/L & Zoom) Control: Control the status of P/L, zoom in/out the camera, adjust the ape ure, foci and setting parameters, run and call the preset.
Lithium Ion Polymer Batteries (3.7V DC3000mAh), more reliable, and work 15 hours
Easy for use that the train is almost unnecessary
Application
CCTV system installation and maintenance
Dome camera and All in one camera testing
The CCTV transmitting channel testing
PTZ controller
Dome camera and All in one camera testing
The CCTV transmitting channel testing
PTZ controller
Family Comparison
| STest-890 | 2.8"TFT-LCD, LCD Brightness/Contrast/Color Saturation are adjustable, NTSC/PAL auto display, Video Level testing, NTSC/PAL color bar generator, PTZ controller, UTP cable tester, PTZ data analyst, PTZ address scanning, Lithium Ion Polymer Battery suppo 11 hours working time. |
| STest-891 | 2.8"TFT-LCD, LCD Brightness/Contrast/Color Saturation are adjustable, NTSC/PAL auto display, Video Level testing, NTSC/PAL color bar generator, PTZ controller, UTP cable tester, PTZ data analyst, PTZ address scanning, DC12V 1A power output for camera, Audio testing, Lithium Ion Polymer Battery suppo 15 hours working time. |
| STest-893 | 3.5"TFT-LCD, LCD Brightness/Contrast/Color Saturation are adjustable, NTSC/PAL auto display, Video Level testing, NTSC/PAL colorbar generator, PTZ controller,UTP cable tester, PTZ data analyst, PTZ address scanning, DC12V 1A power output for camera, Audio testing, Lithium Ion Polymer Battery suppo 12 hours working time. |
| Stest-894 | 3.5"TFT-LCD, LCD Brightness/Contrast/Color Saturation are adjustable, NTSC/PAL auto display, Video Level testing, NTSC/PAL colorbar generator, PTZ controller,UTP cable tester, PTZ data analyst, PTZ address scanning, DC12V 1A power output for camera, Audio testing, Digital multimeter, Lithium Ion Polymer Battery suppo 12 hours working time. |
| STest-895 | 3.5"TFT-LCD, LCD Brightness/Contrast/Color Saturation are adjustable, NTSC/PAL auto display, Video Level testing, NTSC/PAL colorbar generator, PTZ controller,UTP cable tester, PTZ data analyst, PTZ address scanning, DC12V 1A power output for camera, Audio testing, Digital multimeter, Optical power meter, Lithium Ion Polymer Battery suppo 12 hours working time. |
| STest-896 |
3.5"TFT-LCD, LCD Brightness/Contrast/Color Saturation are adjustable, NTSC/PAL auto display, Video Level testing, NTSC/PAL color bar generator, PTZ controller,UTP cable tester, PTZ data analyst, PTZ address scanning, DC12V 1A power output for camera, Audio testing, Optical power meter, Lithium Ion Polymer Battery suppo 12 hours working time. |
Specifications
| Model | CCTV Security Tester 893 |
| Video Test | |
| Signal mode | NTSC/PAL (Auto adapt) |
| Display | 3.5 inch digital TFT-LCD ,960 x 240 resolution |
| LCD adjustment | Brightness, Contrast, Saturation adjustable |
| Video IN/OUT | 1 channel BNC Input & 1 channel Output |
| Video Output Mode | 1.0 Vp-p |
| Video Level test | Video signals measured in IRE or mV |
| Power Output | |
| Power Output | DC12V, 1A |
| Audio Test | |
| Audio input | 1 channel Audio input |
| PTZ controller | |
| Communication | RS232, RS422 simplex and RS485 |
| PTZ Protocol | Compatible with more than 20 protocols such as PELCO-D/P, Samsung, Panasonic, Lilin, Yaan, etc. |
| Baud Rate | 150,300,600,1200,2400,4800,9600,19200bps |
| Video Signal Generation | |
| Color bar generation | Output channel colorbar video signal for testing monitor or video cable |
| UTP CABLE TEST | |
| UTP cable test | Test UTP cable connection status and display in the screen. Read the number of the test box. |
| RS485 data analyst | |
| Data Monitor | Captures and analyzes the command data from controlling device |
| POWER | |
| Power Adapter | DC5V, 2A |
| Battery | Built-in 3.7V Lithium polymer battery ,3000mAh |
| Rechargeable | After charging 4.5 hours, working time lasts 12 hours |
| Low Consumption | Energy saving technology |
| General | |
| Working Temperature | -10°C~+50°C |
| Working Humidity | 30%-90% |
| Dimension/Weight | 175mmx94mmx40mm/360g |
