Simplex Multimode 50/125 10G OM4 Indoor Distribution LSZH Fiber Optical Cable

SKU#:FITB78545WDL
Price: US$ 0.53 ( Per Meter )
Sold: 3377
Availability: In Stock
Qty:
Direct Factory Price Contact Us: Sales@fiberinthebox.com
QtyPrice QtyPrice QtyPrice QtyPrice QtyPrice
1-9US$ 0.53 10-19US$ 0.52 20-49US$ 0.51 50-99 Sign in to view 100+ Sign in to view
fiberinthebox-bbb-a-plus-certification fiberinthebox-product-certification

Simplex Multimode 50/125 10G OM4 Indoor Distribution LSZH Fiber Optical Cable

This Fiberinthebox Distribution LSZH Fiber Optic Cable is used in trunking, LAN and distribution applications where small size, lightweight, and versatile installation capability are required for ducts, LSZH, and air handling spaces. It's ideal configuration for a single termination point requiring multiple fibers. Fiberinthebox Distribution LSZH Fiber Optic Cable is a high performance components and construction and UL Listed in accordance with NEC section 770.179(a) for use in ducts, LSZH, and air-handling spaces. "S"Jacket Indoor-only flexible flame retardant riser jacketed cables available

Application
Used in trunking, LAN and distribution applications where small size, lightweight, and versatile installation capability are required for ducts, LSZH, and air handling spaces Ideal configuration for a single termination point requiring multiple fibers
Features
High performance components and construction High specific strength-to-weight ratio and compact cable design for limited conduit space and tight bends in long cable pulls
Helically stranded core for flexibility, survival in difficult installations, and mechanical protection for the fibers
Lower installed cost High performance tight-buffered coating on each fiber for environmental and mechanical protection
High crush resistance may eliminate the need for innerduct 900μm buffer eliminates the need for costly and time-consuming installation of fanout kits or pigtail splices because connectors terminate directly to the fiber
UL Listed in accordance with NEC section 770.179(a) for use in ducts, LSZH and air-handling spaces
Indoor ("S" Jacket)
Indoor-only flexible flame retardant LSZH  jacketed cables available 2 to 12 fibersCan have interlocking armor applied to cables as an alternative to conduit installation

Specifications

Fiber Count

simplex

Fiber Type

Multimode 50/125 10G OM4 LSZH

Operating Temperature

0℃ to +70℃

Storage Temperature

 -40℃ to +85℃

Installation Temperature

0℃ to +60℃

Flame Retardancy

UL Listed Type OFNP(ANSI/NFPA 262) and FT6(CSA C22.2 No.232)

Crush Resistance

1,500 N/cm

Impact Resistance

Per ICEA-S-83-596

Flex Resustance

1,000 cycles

Diameter

4.7 mm (0.19 in)

Weight

22 kg/km (15 lbs/1,000ft)

Tensile Load-Installation

1400 N (310 lbs)

Tensile Load-Operational

450 N(100 lbs)

Minimum Bend Radius-Installation

7.1 cm (2.8 in)

Minimum Bend Radius-Long Term

4.7cm (1.9 in)



Custom Information
Fiber Coloring: blue, orange, green, brown, slate, white, red, black, yellow, purple, rose, aqua or custom specified Fiber Count: Custom specified Fiber Type: Single-mode, Multimode Sheath Color: Aqua as defaulted or custom specified Sheath Material: PE, AT or custom specified Cable Length: Custom specified
