SMA905-FC Duplex OM2 50/125 Dia2.5mm Fiber Patch Cable

SKU#:FITB37347QOE
Model#: SMA5-FC-DX-OM2-FITB
Price: US$ 62.14
Sold: 3565
Availability: In Stock
Length:
Cable length could be customized in any length as you required.

Qty:
Direct Factory Price Contact Us: Sales@fiberinthebox.com
QtyPrice QtyPrice QtyPrice QtyPrice QtyPrice
1-199US$ 62.14 200-299US$ 60.90 300-499US$ 59.66 500-999 Sign in to view 1000+ Sign in to view
fiberinthebox-bbb-a-plus-certification fiberinthebox-product-certification
SMA905-FC Duplex OM2 50/125 Dia2.5mm Fiber Patch Cable

The SMA-905 optical fiber patch cord, also known as FSMA connector, was one of the First optical fiber interconnect system that gained industry wide acceptance.SMA905 fiber patch cords make use of threaded connections and is still widely used for military, industrial, medical and Surgical applications and laser systems because of their low cost multimode coupling. It features simple termination and Assembly, and is TIA and IEC compliant. SMA 905 multimode connectors are available with stainless alloy or stainless steel ferrules.

Connector Features
1-4- 36 - UNS thread locking mechanism 3.175 mm cylindrical drivepipe Core diameter:0.126mm 0.23mm The minimum bending radius:10D(D:optical fiber Core diameter) Numerical Ape ure:0.4-0.5na Out-Track:2.5mm Inse ion loss:0.5db Wavelength:650nm
Applications
Transmission with low loss, high transmission rate, high precision Laser surgery Photodynamic Therapy Spectral measurement Laser bonding Illumination Sensor

Specifications



The numerical ape ure of the Qua z fiber:

0.22-0.37

Fiber Diameter(mm)

0.2

0.3

0.4

0.5

0.6

0.65

0.8

Minimum Bending Radius

10D (D:optical fiber core diameter)

Fiber Cor(coating layer):

1:1.05 or 1:1.4

Numerical Ape ure

0.21-0.37

            Transmission(%/m0)











Transmission(0.20-0.4um)

85-98

Visible Light(0.4-0.7um)

97-99

Near-Infrared(0.76-1.6um)

90-99

Heliun-Neon(0.6328um)

99

YAG(1.06um)

98

Argon(0.5145um)

98

Transmission Power

>130w(fibre core0.5@1.06um)




Make to Order



     Connector Type

Inner Hole Size

  Concentricity

 Roundness

      Core Material

 Metal Ferrule    Zirconia Ferrule

0.127~1.200mm

   ≤3.0μm

 ≤2.0μm

stainless steel   cupronickel

Notes:
1 The default ferrule of the connector is Metal Ferrule,please post a inquiry for Zirconia Ferrule.

2 The common size standard of Inner Hole is 127+3/-0μm,please kindly enquiry us for other size standards.


Sample Pictures


Buy our SMA905 Fiber Patch Cable with your confidence. Fiberinthebox also can work with your any customization requirements. You can buy SMA905 Fiber Patch Cable with any connectors or lengths. Let Fiberinthebox be your custom optical fiber solution.
