24 Fibers 3In-3Out FS027 Horizontal Fiber Optic Splice Closures

SKU#:FITB39572ZPO
Model#: FS027H-3IO-24
MFG PART#: FS027H-3IO-24
Price: US$ 34.20
Sold: 1855
Availability: In Stock
Qty:
Direct Factory Price Contact Us: Sales@fiberinthebox.com
QtyPrice QtyPrice QtyPrice QtyPrice QtyPrice
1-9US$ 34.20 10-19US$ 33.52 20-49US$ 32.83 50-99 Sign in to view 100+ Sign in to view
fiberinthebox-bbb-a-plus-certification fiberinthebox-product-certification
Description
The horizontal (inline) fiber splice closures are produced to provide space and protection for the optical fiber cable splicing and joint. They are with the perfect sealed design which have the function of waterproof and dust proof. We now provide many kinds of horizontal optical fiber splice closres which vary in sizes, fiber cores types, fused fibers quantity. And they are all with good performance and competitive prices.
Specifications
Maximum capacity:96 Compact size and rugged Suitable for ordinary fiber and ribbon fiber The use of reusable components to open seal in order to ensure a good ai ight waterproof performance. The use of high-strength engineering plastic shell that can endure harsh conditions such as vibration, impact, tensile cable disto ion and strong temperature changes The scope of application : aerial, direct-buried, wall-mounting, duct-mounting, Does not require special tools, easy to install and open the duplicate.Each packing quantity: 9 pieces Number of Fiber Entry: 3in-3out Installable type of fiber splice tray: 24 cores
Scope of application
This Installation Manual is suit for the Fiber Optic Splice Closure (Hereafter abbreviated as FOSC), as the guidance of proper installation. The scope of application is: aerial, underground, wall-mounting, duct-mounting, handhole-mounting. The ambient temperature ranges from -40℃ to +65℃
Sample Picture
Specifications
Model Parameter

Product outlook size 370*185*145
Product material quality PC(Polycarbonate)
Product weight Approximately   3kg
Suitable Dia of cable 8-20mm
Fibers/Tray  24
Max capacity
96 fibers (Bunchy) ; 96 fibers (Ribbon)
Outside box size 44*22*564
Each packing quantity 9 pieces


Product Accessories
