FS3200B Series Handheld Optical Power Meter(-50~+26dBm)

SKU#:FITB99758FMK
Model#: FS3200B
Price: US$ 42.75
Sold: 220
Availability: In Stock

Connector Type:
Qty:
fiberinthebox-bbb-a-plus-certification fiberinthebox-product-certification
Description
FS3200 is a compact and an easy-to-use testing instrument for optical fiber networks, which can be used for absolute optical power measurements as well as for relative loss measurements in optical fibers. The FS3200B power meter features ingenious appearance, wide range of power measurement, high accuracy and user self-calibration function with high performance-to-price ratio. And a special discount will be given you want this FS3200B optical power meter at a large quantity, so please do not hesitate to contact us.



Features
User self calibration function
Comfo able LCD display and optional backlight
LCD display suppo s night operation
Power measurements in dBm or mw and inse ion loss in dB
Low battery consumption, more than 240 hours continual operation time for three 1.5V alkaline batteries
Optional 10 minutes Auto-off function



Applications
Maintenance in CATV
Test Lab of optical fibers
Other Fiber Optic Measurements



Standard Package
FS3200B optical power meter
FC/ Universal 2.5mm adaptor
User manual
Cotton swabs
Soft carrying case



Specifications

Type

FS3200A

FS3200B

Wavelength(nm)

800~1700nm

Detector

InGaAs

Measurement Range

 -70~+10

-50~+26

Uncertainty

+5%

Calibrated Wavelength(nm)

850,980,1300,1310,1490,1550 1625 (more calibrated wavelengths can be optional)

Resolution(dB)

Linear 0.1% or Non-linear 0.01dBm

Optical Connector

FC/ Universal 2.5mm adapter (SC,ST interchangeable connector can be optional)

Power Supply

Alkaline Battery(3 AA 1.5V batteries)

Battery Operating Time

240 h with 1.5V Battery(3)

Operating Temperature(°C)

-10 ~ +60

Storage Temperature(°C)

-25 ~ +70

Relative Humidity

95% (+30°C)

Dimension(mm)

152x74x26

Order Information
FS3200B optical power meter, AC adapter, User manual, Cotton swabs and Soft carrying case.
